Rolling Tolerances
| I Beam | ||
| Height | +3.0mm/-2.0mm | |
| Flange | upto 100mm 100 to 125mm 125 to 200mm | ±2.0mm ±2.5mm ±4.0mm |
| Sectional weight | ±2.5% |
Sizes
I Beams: 125mm x 8mm to 200mm x 100mm
RSJ Poles: 116mm x 100mm to 175mm x 85mm
In case of fixed length supplies, tolerance in length maintained by us will be + 100 mm.
Since inception, Mahavir Steel Industries has always been committed to developing the finest quality structural steel elements that strengthens the core industries of our country and helps it’s all-round, ecofriendly and sustainable growth and development.
Our structural steel range is in conformance to IS 2062 Grade A. We also manufacture in EN8, EN8D, EN9 and EN16, on prior sale and advance intimation. Rugged construction of our MS products assures long lasting life with no maintenance.
MS I Beams
| SIZE | AVERAGE WEIGHT | |
|---|---|---|
| mm | kg/mts | kg/ft |
| 100x50 ST | 8.90 | 2.70 |
| 100x50 LT | 5.30 | 1.60 |
| 125x70 ST | 13.30 | 4.05 |
| 125x70 LT | 9.00 | 2.70 |
| 150x75 ST | 15.00 | 4.60 |
| 150x75 LT | 13.50 | 4.10 |
| 200x100 | 24.20 | 7.40 |
MS RSJ Poles
| SIZE | AVERAGE WEIGHT | |
|---|---|---|
| mm | kg/mts | kg/ft |
| 116x100 | 23.00 | 7.00 |
| 125x70 | 13.30 | 4.00 |
| 175x85 | 19.60 | 6.00 |
